DP30 SERIES HIGH VOLTAGE DIFFERENTIAL PROBES

DP30 series measures voltages of up to 20kVrms and 30kVpeak. They can be integrated into systems using a 3-way mounting capability. The 50 ohms output impedance allows long cable runs far away from the testing equipment without affecting the measurement accuracy.

Highlights & Features:

  • Low Input Capacitance
  • 75 MHz Bandwidth
  • Up To 20 kV RMS, 30 kV Peak
  • Two Standard and Two Precision Models with up to 0.1% DC Accuracy
  • Unmatched Performance when Measuring High CM Slew Rate Signals
  • Digital Offset Adjustment
  • 6V DC in 50 Ω Output Capability

DP30 series models:

  • DP30-2K High Voltage Differential Probe, 1:2000, 12kVrms
  • DP30-10K High Voltage Differential Probe, 1:10000, 20kVrms
  • DP30-2K-LVC Precision High Voltage Differential Probe, 1:2000, 12kVrms
  • DP30-10K-LVC Precision High Voltage Differential Probe, 1:10000, 20kVrms
